5 mm Screw - Cap NMR Tubes

판매가격 72,000 원
카탈로그 NO. FAMILY-19455
제조사/원산지 Wilmad-LabGlass /
제품사양 정보

카탈로그 다운로드

SP Wilmad-LabGlass NMR Consumable and Accessories.pdf
다운로드

Order Information

5 mm Thin Wall Precision Screw-Cap

Catalog No. Description 브랜드 단위 소비자가 추가
Catalog No.507-TR-7 DescriptionNMR Sample Tube 7" L, 300MHz 브랜드Wilmad 단위 소비자가72,000원
Catalog No.507-TR-8 DescriptionNMR Sample Tube 8" L, 300MHz 브랜드Wilmad 단위 소비자가84,000원
Catalog No.528-TR-7 DescriptionNMR Sample Tube 7" L, 500MHz 브랜드Wilmad 단위 소비자가80,000원
Catalog No.528-TR-7-V17M DescriptionNMR Sample Tube 7" L with Short Valve, 500MHz 브랜드Wilmad 단위 소비자가102,700원
Catalog No.528-TR-8 DescriptionNMR Sample Tube 8" L, 500MHz 브랜드Wilmad 단위 소비자가93,400원
Catalog No.535-TR-7 DescriptionNMR Sample Tube 7" L, 600MHz 브랜드Wilmad 단위 소비자가102,000원
Catalog No.535-TR-8 DescriptionNMR Sample Tube 8" L, 600MHz 브랜드Wilmad 단위 소비자가118,900원

선택한 항목

Catalog No. Description 소비자가
총 합계 금액 0원
구매하기
장바구니
찜하기


5 mm Screw-Cap NMR Tubes

Commonly used in sample degasification these tubes can maintain vacuum quality of >10-4 torr. For better vacuum, please check our Pressure/Vacuum Tube and Quick Pressure Valve Tube .Tube comes complete with open top screw cap and septum. Caps and septa can be ordered separately; see table.Note: Items marked CALL may have limited availability.



Details

Screw-Cap Tubes




07-TR-7 Specifications

  • MHz Rating:300
  • Tube O.D. (mm):5
  • Length (inch):7


507-TR-8 Specifications

  • MHz Rating:300
  • Tube O.D. (mm):5
  • Length (inch):8


528-TR-7 Specifications

  • MHz Rating:500
  • Tube O.D. (mm):5
  • Length (inch):7


528-TR-7-V17M Specifications

  • MHz Rating:500
  • Tube O.D. (mm):5
  • Bottom Tube Length (inch):7
  • Valve Length (mm):17


528-TR-8 Specifications

  • MHz Rating:500
  • Tube O.D. (mm):5
  • Length (inch):8


535-TR-7 Specifications

  • MHz Rating:600
  • Tube O.D. (mm):5
  • Length (inch):7


535-TR-8 Specifications

  • MHz Rating:600
  • Tube O.D. (mm):5
  • Length (inch):8



Application Notes

PTFE/Rubber – Laminated discs with a sheath of PTFE bonded chemically to pharmaceutical rubber. Inert to most solvents and many corrosives. Not recommended for multiple punctures.PTFE/Silicone – Laminated discs with a sheath of PTFE bonded chemically to silicone. Inert to most organic solvents and compounds; however, not recommmended for use with strongly corrosive materials. Remains reliable after multiple punctures.
