Bruker® MicroProbe/MicroCryoProbe Sample Tubes

판매가격 78,500 원
카탈로그 NO. FAMILY-1378
제조사/원산지 Wilmad-LabGlass /
제품사양 정보

카탈로그 다운로드

SP Wilmad-LabGlass NMR Consumable and Accessories.pdf
다운로드

Order Information

5 mm Microprobe NMR Sample Tube

Catalog No. Description 브랜드 단위 소비자가 추가
Catalog No.520-1A Descriptionw/2.5 mm O.D.Stem,8" OAL, 800 MHz 브랜드Wilmad 단위 소비자가115,400원
Catalog No.620-1A Descriptionw/1 mm O.D. Stem,8" OAL, 500MHz 브랜드Wilmad 단위 소비자가81,500원
Catalog No.620-1B Descriptionw/1.7 mm Stem, 8" OAL, 500MHz 브랜드Wilmad 단위 소비자가81,500원
Catalog No.620-1C Descriptionw/2 mm O.D. Stem, 8" OAL, 500MHz 브랜드Wilmad 단위 소비자가79,900원
Catalog No.620-1D Descriptionw/2.95 mm O.D.Stem,4" OAL, 500MHz 브랜드Wilmad 단위 소비자가86,000원
Catalog No.620-1E Descriptionw/2.95 mm O.D.Stem,8" OAL, 500MHz 브랜드Wilmad 단위 소비자가78,600원
Catalog No.620-1E-7 Descriptionw/2.95 mm O.D.Stem,7" OAL, 500MHz 브랜드Wilmad 단위 소비자가78,500원
Catalog No.620-1F Description w/2.95 mm O.D.Stem,4" OAL, 500MHz 브랜드Wilmad 단위 소비자가86,000원
Catalog No.620-1G Descriptionw/2 mm O.D. Stem, 4" OAL, 500MHz 브랜드Wilmad 단위 소비자가86,000원
Catalog No.620-1H Descriptionw/1.7 mm O.D. Stem,4" OAL, 500MHz 브랜드Wilmad 단위 소비자가84,300원 품절

선택한 항목

Catalog No. Description 소비자가
총 합계 금액 0원
구매하기
장바구니
찜하기



Bruker® MicroProbe/MicroCryoProbe Sample Tubes

Wilmad has been manufacturing small volume NMR Tubes with the highest quality in the industry to meet the rising demand in small volume NMR. Our Ultra-High Field MicroProbe Tube (>600MHz) is 10 times more precise in terms of camber and concentricity than instrument manufacturers’ stock tubes. This technological advancement helps increase the shimming quality and SNR .



Details

Bruker® MicroProbe/MicroCryoProbe Sample Tubes (Stem Style, Upper OD 5.0 mm, OAL 8″)



520-1A Specifications

  • MHz Rating:800
  • Bruker® Probe Type:2.5mm MicroProbe
  • Stem OD (mm):2.50
  • Stem ID (mm):2.16
  • Stem Volume:183


620-1A Specifications

  • MHz Rating:500
  • Bruker® Probe Type:1.0mm MicroProbe
  • Stem OD (mm):1.00
  • Stem ID (mm):0.80
  • Stem Volume:25


620-1B Specifications

  • MHz Rating:500
  • Bruker® Probe Type:1.7mm MicroCryoProbe
  • Stem OD (mm):1.70
  • Stem ID (mm):1.30
  • Stem Volume:66


620-1C Specifications

  • MHz Rating:500
  • Bruker® Probe Type:3.0/2.5mm CryoProbe
  • Stem OD (mm):2.00
  • Stem ID (mm):1.60
  • Stem Volume:100


620-1D Specifications

  • MHz Rating:500
  • Stem Length (mm):50.0
  • Stem OD (mm):2.95
  • Stem ID (mm):2.41


620-1E Specifications

  • MHz Rating:500
  • Bruker® Probe Type:3.0mm CryoProbe
  • Stem OD (mm):2.95
  • Stem ID (mm):2.41
  • Stem Volume:228


620-1E-7 Specifications

  • MHz Rating:500
  • Bruker® Probe Type:3.0mm CryoProbe
  • Stem OD (mm):2.95
  • Stem ID (mm):2.41
  • Stem Volume (µl):228
  • Overal Length (inch):7


620-1F Specifications

  • MHz Rating:500
  • Stem Length (mm):43.5
  • Stem OD (mm):2.95
  • Stem ID (mm):2.41


620-1G Specifications

  • MHz Rating:500
  • Stem Length (mm):43.5
  • Stem OD (mm):2.00
  • Stem ID (mm):1.60


620-1H Specifications

  • MHz Rating:800
  • Stem Length (mm):43.5
  • Stem OD (mm):1.70
  • Stem ID (mm):1.30
