Stem Coaxial Inserts

판매가격 91,100 원
카탈로그 NO. FAMILY-1379
제조사/원산지 Wilmad-LabGlass /
제품사양 정보

카탈로그 다운로드

SP Wilmad-LabGlass NMR Consumable and Accessories.pdf
다운로드

Order Information

Catalog No. Description 브랜드 단위 소비자가 추가
Catalog No.WGS-10BL DescriptionCoaxial Insert for 10 mm NMR Precision Sample Tube Only 브랜드Wilmad 단위1 EA 소비자가190,700원
Catalog No.WGS-5BL DescriptionCoaxial Insert for 5 mm NMR Precision Sample Tube Only 브랜드Wilmad 단위1 EA 소비자가91,100원
Catalog No.WGS-5BL-SP DescriptionCoaxial Insert for 5 mm NMR Precision Sample Tube; Larger Inner Volume 브랜드Wilmad 단위1 EA 소비자가91,100원

선택한 항목

Catalog No. Description 소비자가
총 합계 금액 0원
구매하기
장바구니
찜하기



Stem Coaxial Inserts

•The most versatile and reliable coaxial system available for various NMR experiments.•General applications include small volume NMR, external referencing or locking and magnetic susceptibility determination.•Ideal for variable temperature studies, all parts are made from Pyrex® glass.Note: Outer tube must be ordered separately based on magnetic field strength.




WGS-10BL Specifications

  • Fits Outer Tube (mm):10
  • Stem Height (mm):50
  • Stem OD (mm):4.0
  • Inner Capacity (microL):410
  • Outer Capacity (microL):2600
  • Use with:513-XPP


WGS-5BL Specifications

  • Fits Outer Tube (mm): 5
  • Stem Height (mm):50
  • Stem OD (mm):2.0
  • Inner Capacity (microL):60
  • Outer Capacity (microL):530
  • Use with:506-PP to 542-PP


WGS-5BL-SP Specifications

  • Fits Outer Tube (mm):5
  • Stem Height (mm):50
  • Stem OD (mm):3.3
  • Inner Capacity (microL):220
  • Outer Capacity (microL):260
  • Use with:506-PP to 535-PP



Application Notes

The upper section of each insert fits snugly into the outer tube, much like a syringe plunger fits in its barrel. The stem is held straight within 0.013mm. Order the outer tube separately.NOTE: #521- caps are 100 or 1000 pk). Cap with hole #521-99010153-100 (100 pk).
