Q Band Standard EPR Tubes

EPR Tube Q-band is the most popular frequency for pulsed and cw-EPR after X-band. The larger Zeeman splitting would benefit EPR studies by (1) improving SNR, (2) requiring less sample, (3) resolving individual components of the g-matrix, (4) disentangling spectra which overlap at X-band, and (5) changing the spectral contribution interaction to field-independent interactions.Wilmad-LabGlass offers high quality EPR consumables to cover these high frequency applications. Table 1: Impurity Analysis for Clear Fused Quartz (unit: ppm in weight)  Al   Ca   Cr   Cu   Fe   K   Li   Mg   Mn   Na   Ti   Zr  15  0.5  <0.05  <0.05  0.1  0.4  0.6  0.05  <0.05  0.3  1.1  0.7  Table 2: Impurity Analysis for Suprasil Quartz (unit: ppm in weight)  Al   Ca   Cr   Cu   Fe   K   Li   Mg   Mn   Na   Ti   Zr  <0.05  <0.05  <0.05  <0.05  <0.05  <0.05  <0.05  <0.05  <0.05  <0.05  <0.05  <0.05  For photochemistry studies, the cut-off wavelength is 265 nm for CFQ and 190 nm for Suprasil.

WG-221T Specifications

• Length (mm):100
• O.D. (mm):1.6
• I.D. (mm):1.1
• Ends:Both ends open
• Package Qty.:10
• Material:CFQ
