AHN myLab Vortex Mixer 2800 rpm

판매가격 342,400 원
카탈로그 NO. 7-110-00-0
제조사/원산지 ahn / Germany
제품사양 정보 Orbital diameter - 4 mm
Speed accuracy - ± 5.0 %
Max. loading capacity - 500 g
Protection class - IP 21
Power supply - 220 ‐ 240VAC, 50Hz
Dimensions (WxDxH) - 205 x 136 x 138.5 mm
Weight - 3.0 kg

카탈로그 다운로드

AHN-Benchtop-Catalogue.pdf

Order Information

AHN myLab® VT-02 Vortex Mixer

Catalog No. Description 브랜드 단위 소비자가 추가
Catalog No.7-110-00-0 DescriptionVortex Mixer 2800 rpm Universal platform 브랜드ahn 단위 소비자가342,400원
Catalog No.7-110-02-0 DescriptionVortex Mixer 2800 rpm Foam for microtubes* 브랜드ahn 단위 소비자가24,700원
Catalog No.7-110-03-0 DescriptionVortex Mixer 2800 rpm Foam for microplate* 브랜드ahn 단위 소비자가24,700원
Catalog No.7-110-04-0 DescriptionVortex Mixer 2800 rpm Rubber holder for flask* 브랜드ahn 단위 소비자가24,700원
Catalog No.7-110-01-0 DescriptionVortex Mixer 2800 rpm Universal platform 브랜드ahn 단위 소비자가24,700원

선택한 항목

Catalog No. Description 소비자가
총 합계 금액 0원


AHN myLab® Vortex Mixer

AHN myLab® Vortex Mixer is suitable for laboratory vortexing of single or multiple tubes. It works with variable speed, reaching 2800 rpm. AHN myLab® Vortexer has a digital speed control, enabling low speed start‐up for gentle mixing and a high speed mixing for vigorous vortexing of the samples. Contact us to test AHN myLab® Vortex Mixer free of charge worldwide.


Multiple operation modes of AHN myLab® Vortex Mixer

AHN myLab® Vortexer offers three operation modes. You can run the device continuously, activate it by touch (pressing down the tube) or put it on stand-by. Choose the most comfortable operation mode for your application with AHN myLab® Vortex Mixer 2800 rpm.


Multiple attachments of AHN myLab® Vortexer

AHN myLab® Vortexer comes with a pre-installed standard cup head, which is suitable for vortexing samples in tubes. Apart from that, you can choose from multiple optional attachments of AHN myLab® Vortex Mixer.
First, you need the universal platform attachment. Having this, you can attach the foam for microtubes, the foam for microplate or the rubber holder for flasks. The front panel of AHN myLab® Vortexer shows you the permissible speed setting for all optional attachments available.


Enjoy the silent and stable operation of AHN myLab® Vortex Mixer!

AHN myLab® Vortex Mixer 2800 rpm works quietly even at the maximum speed. It vortexes with an orbital diameter of 4mm and weights only 3kg. The brushless motor of AHN myLab® Vortexer ensures maintenance-free operation over a longer period of time. Its robust construction guarantees AHN myLab® Vortex Mixer 2800 rpm remains firmly attached to the benchtop, also at the maximum speed.


AHN myLab® Vortexer is suitable for cold rooms and hoods

AHN myLab® Vortex Mixer 2800 rpm tolerates temperatures ranging from 5°C to 40°C, which makes it a good choice for vortexing applications carried out in cold rooms or hoods. The small footprint of AHN myLab® Vortexer optimizes your bench space use.


DescriptionCat. No.
AHN myLab® VT-02 Vortex Mixer 2800 rpm7-110-00-0
Delivery package
1 pc.Vortex Mixer 2800 rpm
1 pc.Power supply adaptor
1 pc.Standard cup head (pre‐installed)
1 pc.Rubber disc attachment
1 pc.Instruction manual
1 pc.Warranty card
Optional attachmentsCat. No.
Universal platform7-110-01-0
Foam for microtubes*7-110-02-0
Foam for microplate*7-110-03-0
Rubber holder for flask*7-110-04-0
Round disk attachmentCRV-30XC-RA
*only applicable in combination with the universal platform 7-110-01-0.
Specifications
Orbital diameter4 mm
Speed accuracy± 5.0 %
Max. loading capacity500 g
Protection classIP 21
Power supply220 ‐ 240VAC, 50Hz
Dimensions (WxDxH)205 x 136 x 138.5 mm
Weight3.0 kg
